LC 0100 Oil-free Claw Vacuum Pump

Core Parameters Overview LC 0100
Motor power 3.0Kw
Ultimate vacuum - 95 Kpa
Rated voltage △200-240V/Y345-415V
Rated flow 100 m3/h
Rated current 12.5△/7.2Y
Maximum blowing force -
Noise level 78 dB
Product weight 145 Kg

Complete Machine Performance Reference Indicators

Ultimate Vacuum Achievement Complies with Nominal
Rated Flow Deviation ≤ ±3%
Noise Control Level Complies with Nominal
Insulation Withstand Voltage Testing Passed Inspection
The above data is based on laboratory standard working condition tests. Actual use effects may vary due to working conditions, environment, and other factors. For specific parameters, please refer to the product manual and actual testing.

Need selection quotation, sample testing, voltage customization?

13827229292

Online Customer Service

You can also use online customer service or Wangwang consultation to obtain detailed information and installation dimension drawings

Your Location: Home > Product > Dry Vacuum Pump > Clawpump > LC 0100 Oil-free Claw Vacuum Pump

Complete Technical Parameters Specifications

ItemParameter (50Hz)Parameter (60Hz)Remark
Motor Power3.0kW3.5kW
Motor PhaseThree-phase
Protection ClassIP54
Insulation ClassClass F
Motor Speed2980 r/min3500 r/min
Input VoltageAC△200-240V/Y345-415VAC△220-275V/Y380-480V
Rated Current12.5Δ/7.2Y10.3Δ/6.0Y
Rated Flow80 m³/h100 m³/h
Vacuum Level5.0 kPa
Max. Leak Rate-
Ambient Temperature5°C~40°C
Operating Humidity90% or below
Noise Level78 dB80 dB
Net Weight185 Kg
Inlet PortG1'1/4
Cooling Method:Air-cooled
CustomizationCustomized leak-proof, explosion-proof and corrosion-resistant construction with thermal protection.
Note: If you need product curve diagrams, CAD installation drawings, or sample testing, please contact customer service to request them; custom voltage versions are available. For equipment selection, it is recommended to confirm the working conditions: required negative pressure, flow rate, continuous working hours, and power supply voltage.
